| Model | BS-128DR | |
| Capacity | Circular @90° | 128mm(5”) |
| Rectangular @90° | 128x150mm(5”x6”) | |
| Circular @60° | 44mm(1.75”) | |
| Rectangular @60° | 44x56mm(1.75”x2.19”) | |
| Circular @45° | 95mm(3.75”) | |
| Rectangular @45° | 75x95mm(3”x3.7”) | |
| Blade speed | @60Hz | 24,35,61MPM |
| @50Hz | 20,29,50MPM | |
| Blade size | 13×0.6x1638mm | |
| Motor power | 375W 1/2HP(3PH), 375W 1/2HP(1PH) | |
| Drive | V-belt | |
| Packing size | 96x54x61cm | |
| N.W./G.W. | 82/102kg | |
Features:
1. 5” round cutting capacity
2. Belt drive, 3 cutting speed
3. Head miters 60° left and 45° right.
4. Wheels on stand, easy moving to different workplace
5. Quick clamping vice
6. Stop rod for the same repeatable cutting
