| Model | BS-128HDR | |
| Capacity | Circular @90° | 128mm(5”) |
| Rectangular @90° | 128x150mm(5”x6”) | |
| Circular @60° | 44mm(1.75”) | |
| Rectangular @60° | 44x56mm(1.75”x2.19”) | |
| Circular @45° | 95mm(3.75”) | |
| Rectangular @45° | 75x95mm(3”x3.7”) | |
| Blade speed | @60Hz | 24,35,61MPM |
| @50Hz | 20,29,50MPM | |
| Blade size | 13×0.6x1638mm | |
| Motor power | 375W 1/2HP(3PH), 375W 1/2HP(1PH) | |
| Drive | V-belt | |
| Packing size | 96x54x61cm | |
| N.W./G.W. | 85/105kg | |
Features:
1. Cut up to 5” round at 90°
2. Saw bow miters 60°left and 45°right
3. Belt drive, 3 cutting speed for different material
4. Stop rod help you to make repeatable cuts
5. Single phase motor suitable for home use
6. Adjustable blade guide move as close as possible to the material to produce accurate cut
7. Hydraulic descent, speed adjustable
