| Model | BS-115 | |
| Capacity | Circular @90° | 115mm(4.5”) |
| Rectangular @90° | 100X150mm(4”x6”) | |
| Circular @45° | 100mm(4”) | |
| Rectangular @45° | 60x100mm(2.4”x4”) | |
| Blade speed | @60Hz | 24,35,61MPM |
| @50Hz | 20,29,50MPM | |
| Blade size | 13×0.6x1538mm | |
| Motor power | 375W 1/2HP(3PH), 550W 3/4HP(1PH) | |
| Drive | V-belt | |
| Packing size | 96x44x46cm | |
| N.W./G.W. | 50/55 kg | |
Features:
1. The maximum cutting capacity is 115 mm (4.5”).
2. Light duty, comes with wheels on stand for easy moving
3. Belt drive, 3 cutting speed for different materials
4. The saw bow can rotate from 0° to 45°
5. Vertical cutting available
6. Quick moving vice for fast clamping and realease
