| Model | BS-912GR |
| Cut circular @90° | 229mm (9″) |
| Cut rectangular @90° | 178x305mm (7″x12″) |
| Cut circular @45° | 150mm (6″) |
| Cut rectangular @45° | 127x150mm (5″x6″) |
| Blade speed @60HZ | 38, 78, 115 MPM |
| Blade speed @50HZ | 31, 65, 95 MPM |
| Blade size | 27×0.9x2655mm |
| Motor Power | 1.1kW 1.5HP (3PH or 1PH) |
| Drive | Gear |
| Packing size | 160x76x125 cm |
| N.W./G.W. | 220/290 kg |
Features:
1. Max. cutting 9″ round
2. Gear drive, 3 cutting speed.
3. Cutting speed adjust on the gear box directly, easy operation
4. Saw bow miter max. 45°, avoid moving heavy material
5. Wheels on the stand make the machine portable
6. Standard coolant system maximum cutting efficiency
7. Adjustable blade guides attached to the saw head, help align the saw blade and increase the lifetime of use
